Reel

@volvo-cars/css v2.3.0@volvo-cars/react-headless v0.24.7

A reel is a horizontally scrolling full-width container. Frames are placed side by side — if they all fit in the viewport they display without scrolling, otherwise the reel becomes scrollable. Apply the .reel class to the container and .snap-start to each child frame. Use the useReel hook from @volvo-cars/react-headless for navigation arrows and active-frame tracking.

Frame 1

Frame 2

Frame 3

Frame 4

Frame 5

Frame 6

Frame 7

Frame 8

import { useReel } from '@volvo-cars/react-headless';
import { useRef } from 'react';

export function BasicReel() {
  const ref = useRef<HTMLDivElement>(null);
  const { reelProps } = useReel({ ref });

  return (
    <section
      ref={ref}
      className="reel gap-x-gridded-element"
      aria-label="Example frames"
      {...reelProps}
    >
      {Array.from({ length: 8 }, (_, i) => i + 1).map((frame) => (
        <div
          key={frame}
          className="snap-start flex items-center justify-center bg-secondary p-24 shape-default"
          style={{ minWidth: '12rem', minHeight: '8rem' }}
        >
          Frame {frame}
        </div>
      ))}
    </section>
  );
}

Spread previousButtonProps and nextButtonProps onto icon buttons to add back/forward navigation. The hook manages disabled state and hides the buttons from assistive technology since the scroll container is already keyboard-navigable.

Frame 1

Frame 2

Frame 3

Frame 4

Frame 5

Frame 6

Frame 7

Frame 8

Frame 9

Frame 10

import { useReel } from '@volvo-cars/react-headless';
import { IconButton } from '@volvo-cars/react-icons';
import { useRef } from 'react';

export function ReelWithArrows() {
  const ref = useRef<HTMLDivElement>(null);
  const { previousButtonProps, nextButtonProps, reelProps } = useReel({ ref });

  return (
    <div>
      <section
        ref={ref}
        className="reel gap-x-gridded-element"
        aria-label="Scrollable frames"
        {...reelProps}
      >
        {Array.from({ length: 10 }, (_, i) => i + 1).map((frame) => (
          <div
            key={frame}
            className="snap-start flex items-center justify-center bg-secondary p-24 shape-default"
            style={{ minWidth: '12rem', minHeight: '8rem' }}
          >
            Frame {frame}
          </div>
        ))}
      </section>
      <div className="flex items-center gap-8 mt-24 justify-end">
        <IconButton
          icon="chevron-back"
          variant="filled"
          color="subtle"
          {...previousButtonProps}
        />
        <IconButton
          icon="chevron-forward"
          variant="filled"
          color="subtle"
          {...nextButtonProps}
        />
      </div>
    </div>
  );
}

Card content

Reels work well for browsing product cards. Set a width on each card and use flex-shrink-0 to prevent them from collapsing. The last card should always be partially visible to indicate more content.

EX30

Electric SUV

EX90

Electric SUV

XC90

Plug-in hybrid SUV

XC60

Plug-in hybrid SUV

XC40

Mild hybrid SUV

import { useReel } from '@volvo-cars/react-headless';
import { IconButton } from '@volvo-cars/react-icons';
import { useRef } from 'react';

const cards = [
  { title: 'EX30', subtitle: 'Electric SUV', image: 'ex30' },
  { title: 'EX90', subtitle: 'Electric SUV', image: 'ex90' },
  { title: 'XC90', subtitle: 'Plug-in hybrid SUV', image: 'xc90' },
  { title: 'XC60', subtitle: 'Plug-in hybrid SUV', image: 'xc60' },
  { title: 'XC40', subtitle: 'Mild hybrid SUV', image: 'xc40' },
];

export function ReelCards() {
  const ref = useRef<HTMLDivElement>(null);
  const { previousButtonProps, nextButtonProps, reelProps } = useReel({ ref });

  return (
    <div>
      <section
        ref={ref}
        className="reel gap-x-gridded-element"
        aria-label="Car models"
        {...reelProps}
      >
        {cards.map(({ title, subtitle, image }) => (
          <div
            key={title}
            className="snap-start flex-col flex-shrink-0 bg-secondary p-24 shape-default gap-8"
            style={{ width: 'min(65vw, 16rem)' }}
          >
            <img
              className="img aspect-3/2 object-contain"
              src={`/images/cars/thumbnails/${image}.avif`}
              width="400"
              height="300"
              alt={`Volvo ${title}`}
            />
            <p className="font-20 font-medium">{title}</p>
            <p className="text-secondary font-14">{subtitle}</p>
          </div>
        ))}
      </section>
      <div className="flex gap-16 mt-24 justify-end">
        <IconButton
          icon="chevron-back"
          variant="filled"
          color="subtle"
          {...previousButtonProps}
        />
        <IconButton
          icon="chevron-forward"
          variant="filled"
          color="subtle"
          {...nextButtonProps}
        />
      </div>
    </div>
  );
}

Hidden scrollbar

Add the .scrollbar-none utility class to hide the native scrollbar. Only use this when you provide other visual indicators (like navigation arrows) that more content is available off-screen.

Frame 1

Frame 2

Frame 3

Frame 4

Frame 5

Frame 6

Frame 7

Frame 8

Frame 9

Frame 10

import { useReel } from '@volvo-cars/react-headless';
import { IconButton } from '@volvo-cars/react-icons';
import { useRef } from 'react';

export function ReelHiddenScrollbar() {
  const ref = useRef<HTMLDivElement>(null);
  const { previousButtonProps, nextButtonProps, reelProps } = useReel({ ref });

  return (
    <div>
      <section
        ref={ref}
        className="reel gap-x-gridded-element scrollbar-none"
        aria-label="Scrollable frames"
        {...reelProps}
      >
        {Array.from({ length: 10 }, (_, i) => i + 1).map((frame) => (
          <div
            key={frame}
            className="snap-start flex items-center justify-center bg-secondary p-24 shape-default"
            style={{ minWidth: '12rem', minHeight: '8rem' }}
          >
            Frame {frame}
          </div>
        ))}
      </section>
      <div className="flex gap-16 mt-24 justify-end">
        <IconButton
          icon="chevron-back"
          variant="filled"
          color="subtle"
          {...previousButtonProps}
        />
        <IconButton
          icon="chevron-forward"
          variant="filled"
          color="subtle"
          {...nextButtonProps}
        />
      </div>
    </div>
  );
}

CSS-only

The .reel class provides horizontal scrolling with snap points without JavaScript. This is useful for server-rendered content or simple layouts that don’t need navigation controls.

Frame 1

Frame 2

Frame 3

Frame 4

Frame 5

Frame 6

Frame 7

Frame 8

<section class="reel gap-x-gridded-element" aria-label="Example frames">
  <div
    class="snap-start flex items-center justify-center bg-secondary p-24 shape-default"
    style="min-width: 12rem; min-height: 8rem"
  >
    Frame 1
  </div>
  <div
    class="snap-start flex items-center justify-center bg-secondary p-24 shape-default"
    style="min-width: 12rem; min-height: 8rem"
  >
    Frame 2
  </div>
  <div
    class="snap-start flex items-center justify-center bg-secondary p-24 shape-default"
    style="min-width: 12rem; min-height: 8rem"
  >
    Frame 3
  </div>
  <div
    class="snap-start flex items-center justify-center bg-secondary p-24 shape-default"
    style="min-width: 12rem; min-height: 8rem"
  >
    Frame 4
  </div>
  <div
    class="snap-start flex items-center justify-center bg-secondary p-24 shape-default"
    style="min-width: 12rem; min-height: 8rem"
  >
    Frame 5
  </div>
  <div
    class="snap-start flex items-center justify-center bg-secondary p-24 shape-default"
    style="min-width: 12rem; min-height: 8rem"
  >
    Frame 6
  </div>
  <div
    class="snap-start flex items-center justify-center bg-secondary p-24 shape-default"
    style="min-width: 12rem; min-height: 8rem"
  >
    Frame 7
  </div>
  <div
    class="snap-start flex items-center justify-center bg-secondary p-24 shape-default"
    style="min-width: 12rem; min-height: 8rem"
  >
    Frame 8
  </div>
</section>

Arrow Left / Right — scroll through frames when the reel has focus.
Tab — moves focus to focusable children within frames, or to the reel container itself if no focusable children exist.
The useReel hook automatically sets tabIndex={0} on the reel container when it has no focusable children, ensuring keyboard users can scroll with arrow keys.

Accessibility

Key consumer responsibilities from the WCAG audit:

Labelling — provide aria-label or aria-labelledby on the scrollable container so screen readers can announce its purpose.
Navigation buttons — previousButtonProps and nextButtonProps include aria-hidden="true" since the reel is already keyboard-navigable.
Focus management — with focusable children (links, buttons), keyboard users navigate by focusing each item. Without focusable children, useReel makes the container itself focusable.
Reduced motion — the .reel class respects prefers-reduced-motion by disabling smooth scrolling.

Hooks

See the useReel hooks documentation for full API reference, options, and return values.
