Selectable Cards

Use CheckboxCard for independent multiple selection and RadioCard within a RadioGroup for a single selection.

Select trim level

Core

550 000 kr

Base configuration with essential features

Plus

625 000 kr

Enhanced comfort and convenience features

Ultra

750 000 kr

Premium features and advanced technology

Show codeHide code

import { RadioCard, RadioGroup } from '@volvo-cars/react-forms';

export function RadioCardGroup() {
  return (
    <RadioGroup name="trim" legend="Select trim level" defaultValue="core">
      <RadioCard
        value="core"
        title="Core"
        meta="550 000 kr"
        description="Base configuration with essential features"
      />
      <RadioCard
        value="plus"
        title="Plus"
        meta="625 000 kr"
        description="Enhanced comfort and convenience features"
      />
      <RadioCard
        value="ultra"
        title="Ultra"
        meta="750 000 kr"
        description="Premium features and advanced technology"
      />
    </RadioGroup>
  );
}

Checkbox card

Use CheckboxCard when users can select multiple options independently.

Extended warranty

12 000 kr

3 years extended warranty coverage

Show codeHide code

import { CheckboxCard } from '@volvo-cars/react-forms';

export function BasicCheckboxCard() {
  return (
    <CheckboxCard
      name="warranty"
      title="Extended warranty"
      meta="12 000 kr"
      description="3 years extended warranty coverage"
    />
  );
}

With image

Cards can include an image for visual identification. Pass an object with src and optional alt, loading, and aspectRatio properties.

Group

Stack multiple checkbox cards using the stack-16 utility class.

Radio card

Use RadioCard within a RadioGroup for single-selection scenarios. The RadioGroup provides the shared name attribute and manages selection state.

Controlled and uncontrolled

Uncontrolled

By default, cards manage their own state. Use defaultChecked on CheckboxCard or defaultValue on RadioGroup to set the initial selection.

Controlled

For controlled behavior, use checked and onChange on CheckboxCard, or value and onChange on RadioGroup.

Interactive content

When you need interactive elements (buttons, links) inside the card, use the React components. Interactive elements inside a CSS-only <label> wrapper are not accessible.

CSS-only usage

For simple cases without interactive elements inside the card, use the .selectable-card CSS class with a <label> wrapper.

Content slots

The card uses a slot-based layout:

• slot="title" – Primary label
• slot="meta" – Secondary information
• slot="description" – Additional details
• slot="image" – Optional image

Autosmmdlgxl

volvocars.com

Show codeHide code

<label class="selectable-card">
  <input type="checkbox" />
  <div
    slot="image"
    class="bg-feedback-gray flex items-center justify-center h-full"
  >
    <code>image</code>
  </div>
  <code slot="title">title</code>
  <code slot="meta">meta</code>
  <code slot="description">description</code>
</label>

Radio group

For radio buttons, give all inputs the same name attribute.

Core 550 000 kr

Base configuration with essential features

Plus 625 000 kr

Enhanced comfort and convenience features

Ultra 750 000 kr

Premium features and advanced technology

Show codeHide code

<div class="stack-16">
  <label class="selectable-card">
    <input type="radio" name="trim" checked />
    <span slot="title">Core</span>
    <span slot="meta">550 000 kr</span>
    <div slot="description">
      <span>Base configuration with essential features</span>
    </div>
  </label>

  <label class="selectable-card">
    <input type="radio" name="trim" />
    <span slot="title">Plus</span>
    <span slot="meta">625 000 kr</span>
    <div slot="description">
      <span>Enhanced comfort and convenience features</span>
    </div>
  </label>

  <label class="selectable-card">
    <input type="radio" name="trim" />
    <span slot="title">Ultra</span>
    <span slot="meta">750 000 kr</span>
    <div slot="description">
      <span>Premium features and advanced technology</span>
    </div>
  </label>
</div>

With image

Add an <img> with slot="image" for visual content. The image stacks above content at narrow widths. See Media for the .img base class and aspect-ratio utilities.

Accessibility

Cards provide accessible labels through the semantic relationship between the <label> (or React component) and the input. The entire card is clickable, providing a large touch target.

Key considerations:

• Do not place interactive elements (links, buttons) inside CSS-only cards wrapped in <label> – use the React components instead
• For radio groups, wrap cards in a <fieldset> with <legend> (the RadioGroup component handles this)
• Provide meaningful alt text for images, or use alt="" with aria-hidden="true" for decorative images

See the accessibility guidelines for detailed WCAG compliance information.

Props

CheckboxCard

Prop	Type	Required	Default
name	string	-	-
The name of the input to use when submitting the form.
value	string	-	on
The value of the checkbox that will be submitted with the form data. @see https://developer.mozilla.org/en-US/docs/Web/HTML/Element/input/checkbox#value
disabled	boolean	-	false
Whether the input is disabled.
required	boolean	-	false
Whether the input is required.
onInvalid	FormEventHandler<HTMLInputElement>	-	-
Fires if the input fails validation on form submit.
onFocus	FocusEventHandler<HTMLInputElement>	-	-
Focus event handler.
onBlur	FocusEventHandler<HTMLInputElement>	-	-
Blur event handler.
aria-label	string	-	-
ARIA label for the input.
aria-describedby	string	-	-
ARIA describedby for the input.
aria-invalid	boolean	-	-
ARIA invalid state.
title	string	✓	-
Main title or label for the card.
meta	string	-	-
Optional metadata (e.g., pricing, status).
description	string	-	-
Optional description text.
image	{ src: string; alt?: string; loading?: "lazy" |...	-	-
Optional image configuration. Can be either an object with image properties or a custom React element (e.g., Next.js Image). When using a custom element, ensure it respects the 52px height constraint applied by CSS.
children	ReactNode	-	-
Custom content that renders below the description. Use this for advanced layouts or interactive elements.
aria-labelledby	string	-	-
ARIA labelledby for the input. Only use this when you need to reference multiple elements for the label. The native <label> element already provides proper association.
hidden	boolean	-	-
id	string	-	-
dir	string	-	-
lang	string	-	-
slot	string	-	-
translate	"yes" | "no"	-	-
className	string	-	-
style	CSSProperties	-	-
tabIndex	number	-	-
onPointerDown	PointerEventHandler<Element>	-	-
onPointerEnter	PointerEventHandler<Element>	-	-
onPointerLeave	PointerEventHandler<Element>	-	-
onPointerMove	PointerEventHandler<Element>	-	-
onPointerUp	PointerEventHandler<Element>	-	-
checked	boolean	-	-
Whether the checkbox is checked. Makes the input controlled.
onChange	ChangeEventHandler<HTMLInputElement, Element>	-	-
Fires when the input is checked or unchecked.
defaultChecked	boolean	-	-
Whether an (uncontrolled) checkbox is checked by default.

RadioCard

Prop	Type	Required	Default
value	string	-	on
The value that will be submitted with the form data if the radio is selected. @see https://developer.mozilla.org/en-US/docs/Web/HTML/Element/input/radio#data_representation_of_a_radio_group
disabled	boolean	-	-
Whether the input is disabled.
onInvalid	FormEventHandler<HTMLInputElement>	-	-
Fires if the input fails validation on form submit.
onFocus	FocusEventHandler<HTMLInputElement>	-	-
Focus event handler.
onBlur	FocusEventHandler<HTMLInputElement>	-	-
Blur event handler.
aria-label	string	-	-
ARIA label for the input.
aria-describedby	string	-	-
ARIA describedby for the input.
aria-invalid	boolean	-	-
ARIA invalid state.
title	string	✓	-
Main title or label for the card.
meta	string	-	-
Optional metadata (e.g., pricing, status).
description	string	-	-
Optional description text.
image	{ src: string; alt?: string; loading?: "lazy" |...	-	-
Optional image configuration. Can be either an object with image properties or a custom React element (e.g., Next.js Image). When using a custom element, ensure it respects the 52px height constraint applied by CSS.
children	ReactNode	-	-
Custom content that renders below the description. Use this for advanced layouts or interactive elements.
aria-labelledby	string	-	-
ARIA labelledby for the input. Only use this when you need to reference multiple elements for the label. The native <label> element already provides proper association.
hidden	boolean	-	-
id	string	-	-
dir	string	-	-
lang	string	-	-
slot	string	-	-
translate	"yes" | "no"	-	-
className	string	-	-
style	CSSProperties	-	-
tabIndex	number	-	-
onPointerDown	PointerEventHandler<Element>	-	-
onPointerEnter	PointerEventHandler<Element>	-	-
onPointerLeave	PointerEventHandler<Element>	-	-
onPointerMove	PointerEventHandler<Element>	-	-
onPointerUp	PointerEventHandler<Element>	-	-

RadioGroup

Prop	Type	Required	Default
legend	ReactNode	✓	-
The legend to show above the radio group.
name	string	✓	-
The name of the radios to use when submitting the form.
hint	ReactNode	-	-
Additional hint or description for the entire radio group.
children	ReactNode	✓	-
The radios.
required	boolean	-	-
Makes the radio group required.
onChange	ChangeEventHandler<HTMLInputElement, Element>	-	-
Fires when a radio is selected.
onInvalid	FormEventHandler<HTMLFieldSetElement>	-	-
Fires if the radio group fails validation on form submit.
disabled	boolean	-	false
Disable all radios in the group. Use sparingly as it can be non-obvious to users why an input has been disabled. Prefer showing validation messages and hints instead.
readOnly	boolean	-	false
Makes the radios in the group read-only. Use sparingly, it's often preferred to present the data as regular text or in a table instead.
form	string	-	-
Id of a form element that the radios should be associated with. Defaults to the containing form element.
enterKeyHint	"done" | "go" | "next" | "previous" | "search" ...	-	-
errorMessage	string	-	-
Set the error message of a radio group and mark it invalid.
aria-invalid	boolean	-	false
Force the radio group to be invalid.
value	string	-	-
Select the radio with this value. Either `value` or `defaultValue` must be set. Makes the radio group controlled.
defaultValue	string	-	-
Select the uncontrolled radio with this value by default. Either `defaultValue` or `value` must be set.
hidden	boolean	-	-
id	string	-	-
title	string	-	-
dir	string	-	-
lang	string	-	-
slot	string	-	-
translate	"yes" | "no"	-	-
className	string	-	-
style	CSSProperties	-	-
tabIndex	number	-	-
onPointerDown	PointerEventHandler<Element>	-	-
onPointerEnter	PointerEventHandler<Element>	-	-
onPointerLeave	PointerEventHandler<Element>	-	-
onPointerMove	PointerEventHandler<Element>	-	-
onPointerUp	PointerEventHandler<Element>	-	-
